Transportation & Automotive - 2013
To give one hundred percent free energy means it's worth everything. As today we are faced with Climate & Environment problems plus with that we are also facing Energy problems as today we have lots of new inventions in energy but still we lack to give 100% pure energy.
The energy today what we have is wind mill, fuel, thermal, solar etc but all of these have drawbacks meaning it’s not safe 100%
My invention 100% Free Energy can be used for automotive engine and creating electricity.
In drawing (A) Indicates CRANKSHAFT
(B) Indicates PERMANENT MAGNET ...
Jun 29, 2013
I based my design of 12V braking caliper on articles from SAE International 2001-2006. The articles concerned an Electronic Wedge Brake prototype made by Siemens VDO.
My target was to simplify caliper's mechanics used by Siemens and VDO and try to use as small amount of parts as possible.
Project of this caliper would help reduce time of turning on braking system, increase safety of cars and reduce costs of whole braking system as well by eliminating many peripheral systems like vacuum pump, braking pump, braking fluid and braking lines too.
I think this system has even ...
Objective is to improve burning, reduce pollution and extract more power from 4 stroke IC engine which follows Carnot cycle. Following suggestions have been made.
• Currently entire Carnot cycle consisting of 4 strokes is executed in a single cylinder- may be the automobiles may have many such cylinders. But in the proposed modification currently used one cylinder is split into two.
• Suction, compression will be in one cylinder which is at normal room temperature and hence fuel-air mixture ratio is unaffected by hot gases. In-coming fuel-air mixture and out going polluted gases do not mix at all..
There is a growing scientific consensus that the point of ‘peak oil’ passed around 2011 and that viable global oil reserves will be severely depleted from 2030. The long term future of terrestrial surface transport is electrification but the foreseeable future must involve a cost-effective compromise, using an EV system for ‘town’ driving and an internal combustion engine for ‘country’ driving. The 48V Town & Country Hybrid Powertrain (TC48) is game-changing because it shows how to deliver CO2 and pollution free urban traffic by 2030 - in a way that the average customer can afford without government subsidy.
Lake Zurich, Illinois
Jun 22, 2013
A new class of heavily cold rolled and thermally processed (HCR-TP) sheet metals is proposed as a viable low cost alternative to producing light weight vehicles for the transportation industry. Presently, automobile and light truck manufacturers are adapting to rising fuel costs by lightweighting vehicles and making revolutionary changes to powertrains. This new class of materials is based on ferrous and nonferrous sheet metals and alloys that can provide the industry with a highly sought combination of features and properties – light weight, high strength, good formability, and low cost. The new class of HCR-TP materials of choice includes ...
Minsk, The Republic of Belarus
The Republic of Belarus
May 3, 2013
Well-known are Atkinson and Miller cycles. These are cycles with varying compression and expansion ratios. Application of these cycles makes it possible to use working gas energy to a fuller extent.
Suggested herein is a different operation mode of a Diesel engine with varying compression and expansion ratios, when the exhaust valve briefly opens and then closes during the compression stroke. The operation is explained in the following drawings:
Fig.1 – the intake stroke;
then the compression stroke starts (Fig.1b);
further on, the exhaust valve is partly opened with air bleeding from the cylinder into the exhaust path ...
The baby-car, which based on an obstacle crossing chassis, is designed for babies and their parents.
It can be easily and smoothly pushed cross the curb onto pavement from asphalt and vice versa.
In the whole process, the baby can be made sure free of any ...
Imagine this. Next time you buy a car, you don’t have to settle for what’s on a dealer’s lot.
Instead, you design your own car. You buy a Ford body, GM chassis, Intel motor controllers, Toyota wheel/motors, Honda electric power unit, IBM car operating system, and Nintendo driver control unit.
You mix and match modules to fit your needs. Then you can upgrade as technology improves.
We have invented that kind of car. With seven “black box” modules, our new modular design marks the first big change in car architecture since Henry Ford’s Model T in ...
One of the main reserves of improvement in fuel efficiency of ground vehicles is reduction of aerodynamic drag constituting (side by side with the resistance of rolling) the principal component consuming normally a bulk of vehicle’s power to overcome it.
Conventional ground vehicles (including cars, SUVs, trucks, etc.) aerodynamically speaking represent bluff bodies: i.e., bodies characterized by separation of flow and high aerodynamic drag, while providing vehicles with low-drag streamlined bodies preventing separation of flow results as a rule in some unpractical shapes with excessive longitudinal dimensions (caused, e.g. by long smoothly tapering tails) that makes this way ...
Jun 26, 2013
The challenge to design the rear suspension of a rear wheel drive sports car has always been one of optimizing the position of both wheels and therefore the contact patch of the tires in order to obtain the maximum possible limit acceleration.
This project takes the active kinematics idea a step further, and for the first time, we present an active system which allows complete control of the wheel by controlling the toe and camber angles on the fly. This allows a more complete control of the contact patch condition which can then further optimize the overall dynamics ...
There are 4 billion tires in the world today. Thermal energy is released mainly from the rolling resistance and is comparable with all the useful energy from power plants on the planet. Into the atmosphere tires release tons of dust and soot.
I present the design and theoretical substantiation of wheel properties.
The wheel’s characteristics maintain that its center of rotation mismatches with the center of support therefore the wheel adjusts its external forces depending on movement conditions. For a driven – pulling wheel the balance of the enclosed forces allows to minimize the demand of the ...
This is just a simple sketch of a car (SUV segment) for easy transport of people and their necessities! The car I've designed is totally virtual design but, imagination has its no limits.
Made of aluminum alloy to reduce weight.
Mostly the parts are not curved which saves the manufacturing process.
The design of the car is compact to utilize all the available space.
The face of the car is kept high to keep safe the passengers.
The body width is more to keep the passengers comfortable for long distance.
The ground clearance is kept high for ...
Mehalla kobra, Al Gharbiyah
May 29, 2013
My project is called Anti-Explosion Tire System (AETS) . The AETS is a system for preventing tires from exploding while driving cars and hence saving the lives of passengers and drivers. AETS consists of 2 components. Fig 1 shows component 1 and fig 2 shows component 2. One outside tire like fig 1 and the other component is inside the tire valve like fig 2.
In fig 1 there's an ultrasonic unit built into the front tire bumper and if there's an obstacle in front of the car tire like big hump or small steel nuts the rays will return ...
The tail rotor takes up 10 to 15% of the power, and complicates the mechanics. Some time ago I checked available designs and was surprised to find test flights in Germany in 1942 and a Dornier design well, a design in 1991/1992. Either compressed air pushes low octane gas through the rotor blades and at the end a spark plug ignites the fuel, driving the blades D (1942), Jet exhaust to the tip of the rotors, or a Zoche diesel driving an impeller and pushing the air into the rotor blades. Yet none of the projects became commercial. Now, ...
Bacolod City, Negros Occidental
Apr 27, 2013
An alternator electricity voltage can reach up to 24 d.c. volts on trucks with maximum electric current of 60 amperes. If ten (10) units of these alternators are installed in a car, then they would provide an electric power up to 14.4 kilowatts or equivalent to at least 22 horsepower. This electric power is strong enough to power a d.c. motor to drive a car, and if coupled with a diesel or gasoline engine will make the system a good hybrid car. If more than ten (10) units of these alternators are installed in a car to power a ...
Amphibious Paddle Boat
This human powered amphibious paddle boat is a water-to-land vehicle that can be used on water as well as on all ground surfaces, including grass, boat slips and sandy beach fronts. Because it can effortlessly transition from land to water with nothing more than continuous pedal action, it can be a crucial support vehicle in water rescue situations. Unlike conventional boat, this boat has two parallel and eccentric wheels on both sides of the boat and two supporting small wheels on the underside of the front and rear ends of the boat to sustain the boat ...
This is basic design proposal for a mass transportation commuter system for Atlanta (or similar geography) which is based on present technology to include the electric automobile. Presently, reverse lanes are being proposed along the I-75/I-575 corridor to solve the commuter congestion problem. The same route could be used to build two narrow lanes designed exclusively for commuter vehicles (including hybrids) with weight/space limits. Vehicle weight and space limitations allow smaller, lighter, lanes to be constructed using new concrete beam and slab manufacturing technology; the track parts are transported to the site and assembled onsite. Power is provided to ...
The AUTO Stop Lamp is a smart brake light that provides added protection for your vehicle, your precious cargo and you. The "AUTO" has two meanings: (1) It's a brake light for AUTOmobiles and (2) It AUTOmatically lights up when the vehicle slows down [patent pending].
• Reduces your chances of being rear-ended
• Provides earlier automatic indication of your vehicle slowing down
• Works even when you don’t apply the brakes in the case of the unexpected such as downshifting, vehicle malfunction, roadway obstacles, and collisions
• Easy for anyone to install – a direct fit ...
The use of aerodynamic devices on semi-trailers, specifically devices located at the rear of the trailer, has been proven to reduce drag and improve fuel efficiency by up to 6%. The addition of such devices help to transition the air that sweeps across the trailer’s top and sides toward the end of the unit, and would otherwise begin to swirl around and create large, standing vortices that increase drag. Current devices require the driver to manually actuate the devices adding time and complexity which is why they have not been accepted in the marketplace. The Kaber-Tail is an aerodynamic ...
CHENNAI, TAMIL NADU
Jun 14, 2013
There has been significant reliance of people on public transport across world of late, Increased reliance would mean a lot to be offered by the transport authorities and the OE manufacturers in terms of the passenger comfort, it becomes challenge though as on one side Passenger comfort is to be given importance and on the other side maximizing the occupancy or other aids for the operator.
As mentioned above passenger comfort has been of utmost importance and this doesn’t confine to be resting on the seat or to travel in the bus, it also has a lot to ...
