Stealth STOVL Mil. Airplane

Votes: 1
Views: 1153
Aerospace & Defense
Previous Next

TWO SEATS (PILOT AND CREW) COMBAT, STEALTH AND STOVL AIRPLANE HAVING THE FOLLOWING MAIN CHARACTERISTICS:

LENGHT= 20,6 m

WINGSPAN= 14,2 m

HEIGHT= 3,66 m (Gears out)

MTOW= about 40,000.00 kgs

CEILING= 60,000.00 ft

SPEED= over 2,2 MACH (IAS)

ENGINES= N.2 PW100 powered FADEC (190 kN per single engine with AB)

FAN LIFT= 90 kN + (12+12 kN) FADEC

WEAPONS (MAIN CONFIGURATION):

- N.1 M61A1 VULCAN 6BARRELS CANNON

- N.1 JDAM JBU-31 (FRONT CENTRAL WEAPON BAY)

- N.2 AMRAAM (FRONT CENTRAL WEAPON BAY)

- N.2 AIM7 SPARROW (FRONT CENTRAL WEAPON BAY)

- N.2 AIM7 SPARROW (SIDEWARD FRONT CENTRAL WEAPON BAY RIGHT AND LEFT SIDE)

- N.2 AIM9 SIDEWINDER (SIDEWARD FRONT CENTRAL WEAPON BAY RIGHT AND LEFT SIDE)

- N.2 AIM7 SPARROW (SIDEWARD REAR WEAPON BAY RIGHT AND LEFT SIDE) (FIRING FROM BEHIND)

- N.2 AIM9 SIDEWINDER (SIDEWARD REAR WEAPON BAY RIGHT AND LEFT SIDE) (FIRING FROM BEHIND)

POSSIBLE AIRPLANE CONFIGURATIONS: STOVL, CTOL, CV, INTRUDER, LIGHT BOMBER.
