Prior to AC all-magnet motors were used for some four decades then forgotten, perhaps from ferrites of the day too weak to be very practical while today with cobalts they are far stronger and last at 90% full power >>700-years.

A recent 1-Megawatt all-magnet generator was developed to have 'no spark', for security to provide power in with explosives and isolated from external needs, has a 50-year, 100%-Continuous Duty-cycle output guarantee with normal service.

A specific design for the Astrobotic M-1 Lander, became a novel geometry of all-magnet motors for electricity of 2.6kw, 110vdc, 24A, 18cm x 7.6cm in diameter replacing a 542w solar panel for use in space.

An advantage for in-transit being aiming with reactors no fuel, allows lunar night survival, no inputs, very little wasteheat, very compact.

To realize and manufacture these for common needs throughout society is a goal for zero emission power available today, aerospace requires long-term power without inputs.

Because the prize is the honor, hopefully it leads to a capital loan for me to have a small design shop to put my 7-tons of tools and all to work again, 30-years as a kitemaker, 7-years a bicycle framebuilder, my first steel design shown needs wind tunnel validation of drag vs aero-sculpted carbon frames to have legs in industry.

Very familiar with oceanography and glaciology, we must end emissions of wasteheat as well, every watt is retaining 1.4 watts sq.m of earth over 1980 values, having aerospace use all-magnet motors is mandatory, there is no fuel-based system equal to freezing a magnetic structure for usable force there, or on Earth.

Voting

Voting is closed!

  • ABOUT THE ENTRANT

  • Name:
    Tom Mallard
  • Type of entry:
    individual
  • Profession:
    Engineer/Designer
  • Tom's favorite design and analysis tools:
    0.5mm Pentel FX, 8.5x11 quad notebooks, hand calculator to cad entry.
  • For managing CAD data Tom's company uses:
    None
  • Tom's hobbies and activities:
    Architecture, bicycles, archeology, aerospace
  • Tom belongs to these online communities:
    GSA
  • Tom is inspired by:
    With a need for zero emission power only few categories of machines can replace Steam Age baseload coal, this commercial unit can flip substations off-grid quickly being a megawatt each and is beyond reproach in proving a modern version and please consider this as a proxy for my 'working prototype' of much smaller machines that require custom ferrite setup and a small assembly line to produce one; http://www.technokontrol.com/en/current-projects/generator.php

    My architectual work applies to off-grid, off everything home•farm•ranch & Class-H to 3-story, much savvy applies to aerospace including using algae to purify wastewater, and, as a junior member of a Moon Mission, spacedecentral.com/coral, the principles became a biological machine as a source of H2O, Watermaker-1, intended for Peregrine M-2 having to attain TRL status for that along with a new geometry of pressure vessel.

    My need is Earnest Money on IP, no royalties, buyer owns it reserving functional QA as designer, Seattle Patent Group retained for such, author of Patent #7,059,618, a fluid automatic bicycle transmission.

    The current motor fits hand power tools, [I became a lead carpenter to be a better architect, did enterprise software, last contracts Xbox Studios], recent work on fireproof tiltup walls layered hemp•mortar & XPS board gives R-40 walls and roof as well.

    Heating uses magnets spun around galvy pipe circulating a thermal fluid powered by a magnetic motor in joist runs, no inputs for the life of the system.

    This principle was applied to a magnet powered thermal motor for lunar night survival supplying lander heating, no inputs, regulated by thermal expansions.

    If UFOs are real, they use magnet motors.

    Best regards, tom
