ICE Vehicle to Hybrid

Votes: 1
Views: 345

There has been a lot of news regarding the banning of the sale of internal combustion engine powered automobiles, in favour of electric motor powered automobiles. What has not been appreciated is even if they did ban the sale of ICE powered automobiles it would take years for the electric powered automobiles numbers to affect the total numbers of automobiles in use. Presently there are 1.42 billion cars in operation worldwide, including 1.6 billion passenger’s cars and 363 million commercial vehicles. In 2018, more than 70 million cars, and around 25 million commercial cars were produced worldwide, while around 2.2 million passenger electric car sales.

My idea is to convert existing ICE cars into hybrids, to run on electric power for low speed inner city use, by adding an electric chain drive, which is fitted to one wheel, the wheel which is not part of the drive system, and is on the driver’s side, or operates on the high side of the road. Most people do not realise that in a normal car that the car is actually powered on one wheel only, this is controlled by the differential in the power train. Like in a motor bike, by fixing the main sprocket to the wheel, and the small sprocket to an electric motor, with a chain running around the sprockets it will be possible to drive the automobile by electric motor only. It is not intended that this system be used when running at high speed or towing a trailer, but would be suitable for inner city and short commuter use.

The conversion would be cheap, use a much smaller battery capacity, and once the general public got used to using electric powered drive, the acceptance of full electric only drive would follow. It follows that the air quality and lower pollution levels would follow with significant health benefits, and clear skies.

Voting

Voting is closed!

  • ABOUT THE ENTRANT

  • Name:
    John Ettridge
  • Type of entry:
    individual
  • Profession:
    Inventor
  • Number of times previously entering contest:
    7
  • John is inspired by:
    John Patrick Ettridge, a long time inventor, was awarded a GOLD Medal at INPEX - Invention and New Product Exposition 2004 held in Pittsburgh, Pennsylvania, U.S.A. and received a GOLD Medal for another invention at the International Exhibition of Inventions, New Techniques and Products 2004, held in Geneva, Switzerland. He has been awarded design awards and published in Nexus Magazine. He has had more than 50 patents granted to him on various inventions.
  • Software used for this entry:
    n/a
  • Patent status:
    none
