Harvesting energy effectively is of paramount importance to maximize energy production capacity. In order to produce electric energy eternally without fuel, I have successfully developed a new concept after spending several years of research. This is the ever needed permanent solution for sustainable energy needs. This device can generate power, eternally. It generates power from action/reaction and back EMF, so it does not require fuel to operate.

This concept consists of one outer stator and two concentric rotors. There are permanent U-magnets on outer stator. There are coil wound straight (bar) electromagnets on outer rotor; and there are permanent U-magnets on inner rotor. One U-magnet on outer stator and two straight electromagnets on outer rotor and one U-magnet on inner rotor forms a magnetic circuit.

Working- rotor coils rotate counter clockwise reaction of that makes permanent magnet rotor rotate in clockwise direction this motion of permanent magnet rotor causes reaction in outer rotor in clockwise direction this causes a current generated in outer coils. The energy that produces electricity comes from reaction (Newton’s third law). Every electric motor has reaction; this reaction force is lost to move earth for a minuscule amount, if motor is attached rigidly to earth by mountings. Famous examples of reaction forces in moving vehicle are, the front end of an accelerating car rises upward due to reaction forces from tire and road. Another example is in helicopters, tail end rotors are used to suppress the reaction of main rotor blades at top of helicopter which gives lift. Otherwise helicopter body will rotate in opposite direction of main rotor. In my concept this reaction force is used to generate electricity; this reaction force in general cases are suppressed.

If you consider 1N of force is applied on rotor then 1N reaction force applied on stator as reaction; since stator is connected to earth in normal generators that 1N of reaction forces is used to move earth then the resultant movement of stator and earth will be negligible. But in my concept; that 1N force rotates outer rotor with some angular velocity. That 1N reaction force is converted to electrical energy. The said 1N force will do same amount of work on inner rotor and outer rotor in opposite directions. This work done by outer rotor will generate electricity in outer coils.

When an action takes place equal and opposite amount of momentum is imparted on other body. if bullet fired from gun has some momentum same momentum in opposite direction is imparted to gun. since conservation of momentum says if no external force is applied, momentum of a system of objects will conserve. velocity magnitude of gun is low since mass of gun is higher than bullet(momentum = mass X Velocity) but both gun and bullet has equal amount of momentum but in opposite direction.

This device can be used as prime mover of automobiles, marine and aerial vehicles. this device can also be used as power generation unit of common house holds to large industries.
