The submitted motor-generator for an electric car has many rotors. But it differs from usual that radiuses of rotors are various. This difference of radiuses allows to use energy of centrifugal acceleration for reception of superfluous capacity.

During start all rotors work in a mode of the motor. At higher speeds or during a stop at a traffic light only the central big rotor works in a mode of the motor. Other rotors with small radius work in a mode of the generator and charge the accumulator. Rotors can be in quantity 3 too.

At very high speeds 2/3 of coils of the big rotor can work in a mode of mutual generation. I.e. only 1/3 coils will consume ...

This novel invention uses polishing techniques to slowly polish or abrade away stepped layers of an object to be scanned. The scanned object is cast into a contrasting resin which provides a dark (or light) background for photography. The layers are digitally photographed stepwise to produce a record of internal structures. 2D digital images are reassembled using computer and software methods to produce exquisitely fine detailed 3D digital models of the solid internal structures in full color.

Because polishing can be controlled tightly, layers may be removed in the in the nanometer realm. This implies the limiting barrier in resolution is the pixel size of the recording camera. These cameras pixels are getting denser and denser as technology progresses ...

A sander is a power tool used to smooth wood and automotive or wood finishes by abrasion with sandpaper. This tool would allow the finishing of irregular shaped by using a hand held drum sander. It also is in particular a self-contained power driven device having a novel method of driving and supporting the sanding drum and retaining the sanding substrate. This device will facilitate the ability of the average handyman to smooth and finish irregular shaped objects, such as table legs, gun stocks, etc., without the need to resort to laborious hand sanding that is required at present for these tasks. This device can also be used for many other finishing functions, similar to a general woodworking sander.

...

The Helium Turbine Engine is an external combustion engine. In this image the burner is designed for burning liquid or gas fuels.

The engine works by heating a propellant made from Helium and two other propellant gases. The propellant gas circulates from the hot side to the 'cold' side, in the process turning a turbine which is attached to permanent magnets. The permanent magnets induce current in an inductor coil. The propellant cycle is a closed cycle.

In this particular design for the Helium Turbine Engine, the inlet takes in already warm air, and passes it over the exhaust manifold, heating it and compressing it even more.

A fuel injection systems introduces fuel into the system, causing it to ...

HYDROXY (HHO) WaterFuelCell EVALUATION TEST SETUP

Using water as a clean economical fuel source has been the dream of mankind for centuries and it now appears this dream has become reality.

On-demand fracturing of liquid water (H2O) to release its Hydrogen (H) and Oxygen (O) components into a combustible gaseous form can employ a variety of methods and techniques. One such technique was pioneered by Stanley Meyer back in the 1980s using a method whereby simple tap water, without additives, is subjected to high voltage pulses within a stainless steel tubular type cell reactor.

Other pioneers, Tay-Hee Han and Christopher Eccles, in about the same time frame developed similar water decomposition methods using high voltage techniques employing dielectric type ...

Natural gas is a booming industry in the US and represents a bridge energy solution to a renewable energy future. Unfortunately, the key piece of equipment, the compressor, that is being used to extract and process natural gas uses technology that has remained fundamentally unchanged in the last century.

OsComp Systems has developed a breakthrough natural gas compression technology that will revolutionize the industry. By combining a novel rotary geometry with an innovative method for extracting heat from the system, OsComp's compressor is 10% of the size of conventional machines and over 30% more efficient.

The basis of the efficiency gains are rooted in basic thermodynamics. As gas is compressed, it naturally heats up. Work that is put into ...

The Lund Technologies Hydrogen Green Lawn System is the world’s first Hydrogen-powered commercial lawnmower system, consisting of both a Walk Behind Mower and a Riding Mower, developed by Lund Technologies, LLC in conjunction with John Deere and Argonne National Labs. Developed for the City of Chicago Parks District, this lawn-care system was designed through more than 10 years of research and discovery in Hydrogen technology. The end result is a sleek and powerful environmentally-friendly lawn system that uses a completely renewable power source, ideal for large scale commercial use.

The Invention Story of the Hydrogen Green Lawn System:

Lund Technologies, LLC was started 10 years ago as the Hydrogen and new technology development sister company of Lund and Company ...

The state of the art solution proposed herein involves the introduction of components made from 2 newly-described, patent-pending crystalline alloys, which compose a multi-sectional pre-fabricated alloy girder-pin frame, which surrounds the entire oil platform (from the vertical level of the platform, all the way down to the mud of the ocean floor). Surrounding this tall cylindrical girder-pin frame, a vertical outer sleeve barrier created by a pair of lap-folded, double-layered, oil impermeable, alloy-fiber and alloy-cable-reinforced cloth sheets, contain all gases and oil escaping within the base of the girder-frame. As the oil and gas rise within this cylindrical containment, two sets of alloy-fiber and alloy-cable reinforced fabric, slip-knot anchored, expansible conical containment barriers capture the collected oil and gases. ...

Cutting of stencils on mylar, paper,or plastic sheets for artwork is usually by Exacto knives, or by modified soldering irons. In this idea, the metal tip of a ballpoint pen is replaced with a glass ball through which a laser beam is focused onto the paper or plastic sheet with which the stencil is to be cut. Advantages over other methods will be in easier control of the tool, and closer cutting tolerances resulting in smoother ...

The Trekr Loop Handle© is a new handle design for mankind’s oldest and simplest machines: hammers, hatchets, pickaxes, etc. The loop design offers several advantages over the traditional handles. The loop end makes losing grip on the handle almost impossible; it would offer an ideal handhold if used on rock-climbing pickaxes. The loop also provides protection for the fingers when striking, which are normally left exposed when griping a traditional handle. The handle will be made with a hollow core, and of reinforced fiberglass or carbon fiber. This will make a very strong yet lightweight handle with better ...
