2010
Machinery & Equipment

The DynaVac is a tool that I invented, developed, applied for a patent on, and marketed mainly to Broadcast Television & Radio stations worldwide to be used to clean electronics and electro-mechanical assemblies better and quicker than traditional methods. In its simplest terms, the DynaVac is basically a hand-held, custom-machined vacuum nozzle with a precision, push-button spray nozzle attached at the vacuum nozzle end. The other end of the fluid push-button assembly tubing is connected to a commercial-grade, pressurized canister of electronics cleaning fluid. The operator turns on the vacuum, typically a shopvac, brings the nozzle tip to within 2-3 inches of the surface or object to be cleaned, presses the spray button and the electronics-grade cleaning fluid coats ...

This machine's concept is one of the non-traditional machining concepts, machining technique based on electrolysis in which metal is tooled in an anodic way and locally dissolved. The basis for this technique was discovered by the greatest experimenter ever Michael Faraday (1791 – 1867)

This concept which depends on the chemical reaction to pull the ions of the material making desired cavity without any stresses (No Physical or Thermal Stresses).

Electrochemical Machining is a relatively old metal machining technique. The base of this technique is already made in the 19th century.

As mentioned the basic concept is Electrolysis, the work piece will be connected as anode, and the tool will be the cathode, for sinking process both cathode and ...

Massive Nibble© needs your vote so we can help feed the world by using our solar-powered Zero Pollution Engine™ in farm tractors and other machinery. Together, we can help feed the world with farm equipment that doesn't pollute and costs almost nothing to operate. Solar-powered equipment will allow crops to be planted, irrigated and harvested at minimal cost, for maximum profit. Family farms can flourish, increasing locally-grown food supplies and enhancing food security. When farming becomes more profitable, more people will get involved and farm children will be motivated to stay on the farm.

The same Zero Pollution Engine™ used to make solar-powered tractors can also be used to power the trucks used to deliver crops and dairy products to ...

Today, fish fillets pin bone removal is a manual process that is labor intensive and can result in painful and permanent carpel tunnel injury for workers. Automated systems can only be used in post rigor mortis situations, and depending on the fish species. Existing solutions involve either labor intensive manual pin bone removal with tweezers, or automated machine removal, which causes significant bone breakage, as well as the difficulty of removal once rigor mortis has set in. There is therefore a clear market need for an automated tool that can be used on several species, including salmon and tilapia, in both pre-rigor and rigor conditions whether fresh or smoked.

This Pro Intech EVF technology was devised to improve the ...

The idea behind Flexible Gear design is to be able to engage and disengage (without grinding gears or destroying equipment) two gears using only Flexible Gears. Even though these gears would be used for light or medium duty operations, the benefits are not only saving money and time but also the noise will be reduced, safety would increase and there will be less maintenance for equipment.
Flexible Gear has three main components:
· Steel (Aluminum) Core, which is Hub with Bore thru the length for the shaft.
· Mid Layer, this would be high density foam or soft durometer rubber.
· Outer Layer, which is very similar to Timing Belt construction, but would have standard geometry of the ...

The function of our production is ‘floor cleaning’. From market survey, we found out two main aspects here:
1. Labour
2. Power usage as we need to use as low as we can.
Another interesting demand was: a mechanism which will dry out floor (Most people use liquid water. High costly equipments use steam and they utilize lots of power). So to meet all these we made something which is completely manually run and add a mechanism like one used in toys’ to run fans. The drying out is especially suitable for humid countries.
Now, according to the pictures, the product can be divided into following parts: Handle, Base, Carriage, Rubbing medium and Gear train. ...

An apparatus and method for capturing 3 dimensional tomographically registered full spectrum computer digitized images of internal structures of specimens is described. Instrument Collected 2D data slices are later processed to create extremely intricate 3D models in full color. They are naturally registered and aligned datasets with detail beyond any known invention that can reveal structure potentially to the 100 nanometer realm.

By use of specialized mounting systems and methods, dried or frozen specimens are cast into rigid optical or opaque mounting compounds in specialized lapidary mounts. The lapidary system uses a lapping wheel platen that is a spinning clear surface where the abrading or cutting surface is in direct contact with an imaging plane. Removing layers of the ...

This is spur gear involute calculator.

Most of the spur gears are made up from gear hobbing technique.

With the development of technology nowadays gears are made from CNC (Computerised Numerical Controlled) machining. The basic inputs for the CNC machines are the co-ordinates of the gear and other machining inputs required for machining a gear from a metal block.
This program helps in calculating the co-ordinates of a spur involute gear from the given inputs like:
1) Centre distance between the two shafts.
2) Teeths required on the gears.
3) Pressure angle of the involute.

The points taken from the program are ready to be given input to any CNC making a gear profile.

The involute profile was derived ...

My all-season ATV track conversion kits convert the rear ATV tires to a tank-like tread system. The track system provides greater contact with the ground, increasing stability and reducing the chance of the ATV from flipping back onto the rider, which may result in serious injuries. The tracks allow the ATV to better maneuver on all surfaces where traditional tires would get stuck or slip (e.g. sand, snow, mud). In addition to the track system, a front end tire to snow ski conversion kit is added. The ski kits allow the ATV to be used during the winter months as a snowmobile, thus giving ATV riders an option to convert their ATV rather than spending many thousands of dollars ...

A high pressure, permanent tube fitting and installation tool has been developed, as well as a serviceable, threaded fitting, to seal high or low pressure fluids and gasses. The installation tool (HFU or Hydraulic Fusing Unit), can generate over 7 tons of output force, with only 50 in-lbs of input torque required. Testing has shown the ability to burst tubing, while maintaining leak free fitting connections. Using a cordless drill for input power, permanent connections can be made up on tubing in 20 seconds, compared to 90 seconds for threaded connections. The small, compact size of the HFU permits tube fitting installation in tight spaces, with a minimal amount of input torque required to complete permanent, leak proof connections, ...

Page 3 of 8
