Machinery & Equipment - 2013
The design is for a segmented welding filler rod for use with oxy-acetylene or TIG welding in steel aluminium copper etc..
The idea behind segmenting the filler rod is to allow the operator to deposit a precise volume of metal in steps along the joint to achieve a so called "fish-scale" or "nickle stack" effect.
The reduced cross section of the rod between segments limits heat conduction along the rod so the rod melts using less heat and allows the use of a larger diameter rod than would normally be used.
Below are three illustrations of the ...
New York, Ny
Jun 27, 2013
The surface of rivers has been used for transportation since man first appeared on this planet.
Slither is a way to utilize the space and energies available under the surface of rivers to significantly expand freight transportation in a green fashion.
Slither is a continuous underwater freight forwarding system, floating inches from the bottom of the river, that captures the energy of the river’s flow for propulsion. The design of Slither is such that the water flowing catches and opens fins built into the side and top of the conveyer, pushing it forward.
We have designed a line of small bore hydraulic cylinders. The one shown has a .375 bore and a 2.500 stroke. The cylinders are made in the U. S. A. and are all Stainless Steel. The hoses and fittings are off the shelf #3 A & N JIC. They use standard hydraulic fluid.
The were designed to actuate a hard to reach location that would not be accessible with a standard push pull cable or a hazardous application.
They can be actuated by a slave cylinder or a small hydraulic ...
This device is designed to be used at building sites for a range of cable installations, including Voice, Data, Security (CCTV) and Fire alarms, Cable TV as well as a range of [round] Electrical cables.
Its purpose is to facilitate a faster and more effective method of laying cables by means of marking cables in continuous segments along the length. This enables the operator to easily identify and segregate cables according to requirements.
The apparatus is compact, easy to carry and quick to assemble on site and requires no power (or batteries) to operate. The marking process is fast ...
Chengalpattu, Tamil Nadu
Jun 24, 2013
Some equipment in industry produces jarring noise while they run and eventually impair our ears. A method to attenuate such noise from equipment is described below. Before describing the concept, the lessons learnt in school Physics is recapitulated. The bell jar experiment may be referred. (Google search may be accessed). In the fore said experiment one calling bell is kept inside a bell jar and power supply is given. We can hear the bell sound from outside. Then gradually the inner space is evacuated and sound level decreases. This shows sound needs a medium for propagation. We ...
This design idea is a speed change mechanism that mainly brings the possibility of high efficiency, avoiding power losses, usual characteristic of mechanical transmissions. For example in the car industry, the automatic transmission and the associated drivetrain usually consume about 20 percent of the engine's power and a manual transmission takes about 16 percent of the power.
One challenge to use magnet rings instead of steel gears in the transmission is to use as large as possible a magnetic area from each magnet ring engaged to increase torque transmission and then reducing the necessary magnet size. Using magnets rings, ...
Srivilliputhur, Virudhunagar District, Tamilnadu
Jul 2, 2013
TRIPLE ACTING PUMP it is named because compression is accomplished at the three sides of the pistons. By using this Triple acting pump we can achieve every high delivery with very high pressure comparing with the exiting one.This TA-pump reduce the Electrical efficiency, mechanical efficiency. As it gives twice the amount of double acting pump’s delivery and pressure,we can use TA-pump wherever high pressure head required.The support in gelement and the mechanism used for this TA-pump give more stability to the system. The special feature of this TA-pump is that there won’t be to&fro shack because in this mechanism ...
Almost every household and service station has an electric drill. A drill’s function is restricted to drilling holes, screwing bolts in and out, or similar processes.
We ask you this question: Would you like to expand your drill’s application to a wider range of functions? If your answer is "YES"!!!, then we can offer you an additional multiple-purpose device called The Hydraulic Adapter. The Hydraulic Adapter allows you to convert your electric drill into an effective liquid dispenser of various water solutions, water-oil emulsions, or paints.
The proposed Hydraulic Adapter was developed on the basis of a unique ...
The Pedal Mower crosses the problematic bridge and solves several problems- rising fuel costs, reliance on foreign fuels, depletion of natural resources, pollution, and rising obesity. This machine solves these problems by allowing a person to mow a lawn, but forces them to pedal the lawn mower like a bike. The solar panel absorbs thermal energy and uses it to keep the motor running that spins the grass-cutting blades and keeps the headlight powered for when you need it. This removes the need for gasoline or another energy starter. The metal treads on each side of the machine help ...
Method of the invention is aimed at manufacturing track membranes. A track membrane is a thin polymer film with through pores which are formed by penetrating a special substance into and through the material of a polymer plate and then removing the traces of penetrated particles from the matrix material thus forming pores. The track membrane may find use in various fields of industry as conventional membrane filters for purification of liquid substances from solid contaminants.
The method is based on the principle of Super Deep Penetration (SDP). A device for realization of the method (see Figure) ...
