This system is a pneumatic electric hybrid. It is a self sustained velocity /pressure cycle that will produce fuel less electricity for unlimited range while charging itself.
From "Start" the battery powers the mapping computers / control boards. The mapping computer allows current from the battery to rotate number 13 (electric motor). This action causes number 14 (permanent magnetic generator) to feed current to number 8 , mapping computer (an active circuit in the "run" position - current from transformer in the battery charger / low tension dc current) and then to feed high tension ac to number 6 (fixed field coil primary generator).
Number 34's (current pick up) output is then fed through number 33 (brush track brushes ...
A Proposed Wind and Renewables Machine Model.
This Proposed Wind Machine Energizes its Rotation by Wind Force, applied on its two Sails [ Photo 1 ].
The Sails assimilate the machine to a “sailboat,” and its name “Argonaut Jason” reminds of the sailboats of the Mythological Era, seeking the “Golden Fleece.” Here the “Golden Fleece” is the “ Free and Clean Energy.”
The Model in Photos 1,2 was tested [ about 20 years ago] under no load, simply for its functional behaviour in the wind.
The model size is relevant to the “handling and palm.”
This form of Renewables proposes Wind Generation together with Photovoltaic Cells Mixed with other Types of Electricity Generating Elements, such as for ...
Many kinds of multicopters have been developed recently. One of the most interesting ways of use is photography from the air. It must be useful that if it were possible that taking pictures of a car from the air by a multicopter. Because it is able to record not only the running car but also surrounding cars.
The problem is that multicopters are not able to fly as fast as cars. To solve it, the gliding function is added. This combined glider and muticopter plane, named "glicopter," is able to fly by itself with its rotors as a muticopter when the car running slow or stopping, and glide with traction through a wire tying between the car and the ...
The design objective was to design a vehicle for the next generation (Generation Z) for the world's largest cities of the future.
The Vehicle is designed around the city of Tokyo for the year 2025, with the aim at bringing excitement back into the commuter's day to day travels. The City of Tokyo, while it has an extremely efficient transportation system that arrives promptly, all of the commuter trains are grossly over capacity, some as close as 200%, which leads to a dismal commute to work.
The inspiration of the vehicle came from science fiction themes like tron, the idea of having a vehicle disappear and re-appear on command was awe inspiring. I wanted to take the excitement of ...
As my invention name is 1>8 Touch Screen, this means 2 screens -- one screen is bigger and another screen smaller. Today we have a mobile revolution as well as tablets. People buy both mobile as well tablets and some people even have a computer, tablet and mobile. 3 of them means more expenditure for people.
To cut the cost as well as less luggage in travelling daily routine to office to home, I I came with revolution to 2 screens -- one screen which can be placed in the office or at home and another screen is mobile.
1>8 Touch Screen which means one big screen size of 7 to 10 inch which we can be ...
170 mpg Hydraulic Hybrid
Lower costs - 0 to 60 in 4 sec. - Travel 1,000 miles
Conventional cars have powerful drivetrains for fast acceleration and brakes to stop the car. They are heavy, costly, space consuming and waste a lot of energy. Only 1/6 of the energy is utilized to drive the vehicle.
The Hydraulic Hybrid is driven by an advanced hydrostatic drivetrain, consisting of a hydraulic free-piston engine, an accumulator and four hydraulic wheelmotors. The engine provides pressurized fluid for charging the accumulator and driving the wheelmotors. When fully charged, the engine is turned off and only fluid from the accumulator drives the car. During braking, the wheelmotors are reversed to pumps, acting as ...
Due to exhausting fossil fuels and other non renewable energy sources, we have to switch to renewable energy sources and completely depend on it in the near future.
One of the best renewable energy source known to us is solar energy compared to other renewable sources. But then also it has some demerits like the solar energy that enters the Earth's atmosphere reduces to about 40 to 50 percent of the initial energy content in space when it reaches the Earth's surface. Another demerit is solar energy is available only in daylight.
So, to solve this problem I thought of concentrating solar energy in space itself where the concentrating panels are orbiting the Earth and ...
270 kts. High Speed Helicopter
310 mph - Lower costs - Higher payload
Conventional helicopters reach speeds of 150 kt. (175 mph) because of the loss of lift forces at the retreating rotor blade at higher speeds. Counter-rotating rotors prevent the effects of the losses, but their mechanisms are very complex, heavy and increase the air drag significantly.
The new high-speed helicopter consists of a simplified conventional main rotor, a tiltable tail rotor, and small wings. Both rotors are in vertical position during takeoff, and the tail rotor additionally slightly tilted sidewise for creating the antitorque for the main rotor.
During the transition, the tail rotor tilts continuously into horizontal position, providing increasing thrust for horizontal ...
This concept is an improvement of the existing 3-Dimmensional Spatial Projector based in 3 dimensional space rasterizing. Particularly this one was inspired by the Stars War movie and is used to project objects in 3 dimensions in a real space. Although the spectator or viewers won't be able to interact within the space of the image it would be able to walk around the Projection Volume and inspect the imaging.
The projector relies on the persistence of the vision to create the effect of a three dimensional object. It consist of a moving translucent screen that rasterizes the volume an reflect a series of "slices" of the three dimensional object as it moves. There are other similar previous art existent, but ...
Our revolutionary 3 IN 1 MINI COFFEE TUBE—AS A CONTAINER, A FILTER AND A STIRRING TOOL ALL IN ONE, filled with fresh ground coffee for making better singe coffee in a simpler way without a specific coffee machine.
A traditional single coffee bag can’t provide a strong enough water circulation for extracting most of the essences and aroma; it makes a weak or bitter beverage. A single cup machine is expensive for most of family. Our single disposable mini coffee tube comprising a porous tube, a rolled filter, a top, and bottom to form a complete container that provides the functions of holding coffee, filtering, and stirring in mugs or a coffee machine during the brewing process. ...
